    ESD Dissipative Pink Poly Manual Stretch Foil | Roll: 500 mm x 200 m x 0,025 mm
    Back

    Anti-Static-ESD-Antistatic-Dissipative-Stretch-Foil-Mechanical-and-Manual
    ESD

    ESD Dissipative Pink Poly Manual Stretch Foil | Roll: 500 mm x 200 m x 0,025 mm

    232.SNN.500.200.00.025.000
    HS Code : 39239000000
    Brand
    17,75 € exc tax
    Packaging Unit :
      Add To Cart
    Tier Ranges Price
    50 - 99+ 17,75 €
      Add To WishList
      Tell A Friend

    Dissipative stretch film ESD are designed to protect in EPA sensitive to static electricity discharge electronic devices and components on pallet. Dissipative stretch film ESD are according with norms IEC61340-5-1; and directive RoHS. *MOQ: Please ask individually

    Available models

    Product Description

    ESD DISSIPATIVE MANUAL STRETCH FILM





    FEATURES



    • Electrostatically dispersive polyethylene foil
    • Foil providing safety against damage caused by electrostatic discharge
    • Non amic material allowing recycling
    • Stretch wrap (stretch foil ) has got quality certificate according to PN-EN (IEC) 61340-5-1 norm and RoHS I REACH directive
    • Color : pink
    • Foil is dedicated for manual use



    TECHNICAL PARAMETERS



    TYPICAL SURFACE RESISTANCE

    Rs= 109 – 1011

    TIME OF CHARGE DECAY

    from 1000V to 100V < 2 seconds

    CONFORMITY WITH THE NORM

    PN–EN (IEC) 61340-5-1

    CONFORMITY WITH UE DIRECTIVE

    RoHS and REACH




    DIMENSIONS (mm)



    Other dimensions are available on request and according to customer needs!



    100 x 250m x 0,06

    450 x 250m x 0,08

    150 x 250m x 0,06

    500 x 250m x 0,08

    200 x 250m x 0,06

    600 x 250m x 0,08

    250 x 250m x 0,06

    700 x 250m x 0,08

    300 x 250m x 0,06

    800 x 250m x 0,08

    350 x 250m x 0,06

    900 x 250m x 0,08

    400 x 250m x 0,08

    1000 x 250m x 0,08
    Technical Details
    Model
    _
    Packaging Category
    Dissipative Stretch Foil ESD / Mechanical & Manual
    Packaging Type
    ESD Dissipative Manual Stretch Foil
    Foil colour
    Pink Transparent
    Material
    Dissipative Polyethylene LLDPE ESD According with Norm EN 613540-5-1 & RoHS
    Overprint
    No Print
    Tolerance dimension
    ± 10 mm
    Tolerance thickness
    ± 0,005 mm
    Thickness
    0,025 mm
    Thickness In µ
    25 µ
    Dimensions
    500 mm x 200 m x 0,025 mm
    Weight
    2,3 Kg
    Norms
    IEC 61340-5-1
    Norms According with directive RoHS
    SGS raport nr. TR142908
    Validity
    1 year
    MOQ
    Please Ask Individually
    Lead Time
    21 Days
    Delivery
    exw. Or DAP + extra delivery costs to Invoice

    All ESD products fulfill the IEC 61340 standards.
    We believe all the information in these pages including technical data to be reliable.
    However we make no warranties expressed or implied and assume no liability regarding any use of this information.
