ESD Standards IEC 61340 ANSI S2020

ESD Standards IEC 61340

Relevant ESD Standards based on Military Specifications.

Protection of electronic devices from electrostatic phenomena
and Electrostatic control for healthcare

IEC 61340 - Protection of electronic devices from electrostatic phenomena

IEC/TR 61340-1:2012 describes the fundamental principles ofelectrostatic phenomena
including charge generation, retention and dissipation and electrostatic discharges.

Methods for measuring electrostatic phenomena and related properties of materials are described in a general way.

Hazards and problems associated with electrostatic phenomena and principles of their control are outlined.
Useful applications of electrostatic effects are summarized.

The purpose of this technical report is to serve as a reference for the development
of electrostatics related standards, and to provide guidance for their end-users.

The contents of the corrigendum of March 2013 and the corrigendum 2 of December 2017 have been included in this copy.

IEC 61340-5-1:2016 is available as IEC 61340-5-1:2016 RLV

which contains the International Standard and its Redline version,
showing all changes of the technical content compared to the previous edition.

IEC 61340-5-1:2016 applies to activities that:

manufacture, process, assemble, install, package, label, service, test, inspect, transport or otherwise handle electrical or electronic parts,
assemblies and equipment with withstand voltages greater than or equal to 100 V HBM, 200 V CDM and 35 V for isolated conductors.

ESDS with lower withstand voltages may require additional control elements or adjusted limits.

Processes designed to handle items that have lower ESD withstand voltage(s) can still claim compliance to this standard.

This standard provides the requirements for an ESD control program.

IEC TR 61340-5-2 [9] provides guidance on the implementation of this standard.

This standard does not apply to electrically initiated explosive devices, lammable liquids, gases and powders.

The purpose of this standard is to provide the administrative and technical requirements for establishing,
implementing and maintaining an ESD control program (hereinafter referred to as the " program"):

This edition includes the following significant technical changes with respect to the previous edition:

a) Technical requirements were changed to align IEC 61340-5-1 with other industry ESD standards;

b) Reference documents were updated to reflect newly released IEC standards;

c) A section on product qualification was added;

d) Table 4 was deleted and detailed packaging requirements were deferred to IEC 61340-5-3;

e) Clause A.1 was removed and is now included in IEC 61340-4-6.

ESD Support ESD Training ESD Workspace Analysis ESD Standards IEC 61340 ANSI S2020

ESD Standards IEC 61340 ANSI S2020 Products (33)

Sort By


Name , AES Article No , Description

Price

ESD Standard - IEC 61340-5-1:2016 - General requirements Protection of electronic devices from electrostatic phenomena

AES-STAND-IEC-61340-5-1-2016

Note: a redline version of this publication exists
IEC 61340-5-1:2016 RLV

PROTECTION OF ELECTRO...

Price On Request
